40 To 200mesh Output Size 60 To 700kg Per Hour Capacity Rice Husk
Grinding Machine
Introduction:rice husk grinding machine
BSZ pin mill is specially used for petroleum products and chemical raw
materials. Such as spices, herbs, cocoa beans, coffee beans, seed
cakes, fruits, nuts, salt, etc. Comply with food hygiene standards,
simple operation and low noise.
This oats rolling machine is suitable for all kinds of food and chemical production and
processing enterprises. It has two-way grinding wheel grinding and
one-way grinding wheel grinding. There is no need for a screen in
the grinding chamber. If you want to change the powder size, you
only need to change the speed through the frequency converter.
Technical data:rice husk grinding machine
| Model | BSZ-350 | BSZ-450 | BSZ-550 |
| Capacity(kg/h) | 60-200 | 150-500 | 230-700 |
| Feed size(mm) | <15 | <15 | <15 |
| Output size(mesh) | 40-1000 | 40-1000 | 40-1000 |
| Cavity disc crush motor(kw) | 18.5 | 22 | 37 |
| Door disc crush motor(kw) | 15 | 18.5 | 30 |
| Feed screw motor(kw) | 0.37 | 0.55 | 0.75 |
| Speed(rpm) | 12000 | 9600 | 8400 |
Working method:rice husk grinding machine
This rice husk powder making machine adopts the method of quantitative feeding to control the even
movement of the material in the abrasive grain. Feeding by negative
pressure traction method. The machine has no screen, the grinding
material fineness can be adjusted by grinding wheel speed. It can
also be graded externally.
Main features:rice husk grinding machine
1. The parts of the machine in contact with the materials to be
crushed are made of stainless steel, which has good anti-corrosion
performance.
2. For the convenience of cleaning, the shell is completely closed.
3. The inner wall is treated, and the surface is smooth, which
ensures that the production of drugs, food, chemical and other
materials is more in line with the national "GMP" standard.
4. There is no screen in the grinding chamber, and the particle
size can be changed by changing the speed.
5. Simple linear structure, convenient installation and
maintenance.
Crushing Effect:rice husk grinding machine
