Superfine Powder Making 60 To 2500mesh Powder Fineness Porang
Machine
Product introduction:porang machine
BSP porang mill( air sorting machine) is one kind may produce the unusual fine
dust the grinder.Uses in the garrulous sugar, the output may reach
60 ~ 1000 item.Uses in grinding the dry ginger and turmeric
yellow.This kind of type also may grind to the extremely thin
powder.Moreover the grinder may produce the extremely even powder
material, the powder material distribution extremely is also even.
Technical data:porang machine
| Model | BSP-350 | BSP-450 | BSP-500 | BSP-750 |
| Input size(mm) | <15 | <15 | <15 | <15 |
| Fineness(mesh) | 60-2500 | 60-2500 | 60-2500 | 60-2500 |
| Capacity(kg/h) | 20-200 | 40-500 | 60-800 | 120-1800 |
| Crush motor(kw) | 11 | 18.5 | 30 | 55 |
| Grade motot(kw) | 1.5 | 4 | 5.5 | 11 |
| Blower(kw) | 7.5 | 11 | 18.5 | 37 |
| Feed motor(kw) | 0.55 | 0.55 | 0.75 | 1.5 |
| Discharge motor(kw) | 0.75 | 0.75 | 1.1 | 1.5 |
| Speed of principle axia(rpm) | -6500 | -5350 | -4600 | -3100 |
| Grading impeller speed(rpm) | 4000 | 4000 | 3500 | 3000 |
| Weight(kg) | 1600 | 1800 | 2300 | 3100 |
Working method:porang machine
The material enters the grinding chamber through the screw
conveyor, where it is cut and ground by the rapidly rotating
blades. The powder enters the classification chamber through the
guide ring. When the grading wheel rotates, air and centrifugal
force act on the powder at the same time. The particles with
particle size larger than the critical diameter (graded particle
size) have greater mass and are thrown back to the grinding chamber
for crushing again. Particles with particle size less than the
critical diameter enter the cyclone separator and dust removal box.
Advantages:porang machine
1. Designs compact, the structure is reasonable.The material
interior is equipped with the graduation organization, may
simultaneously carry on the rubbing and the graduation, reduces the
energy consumption.2. The this aircraft is equipped with the
ventilator to radiate continuously, is suitable for the grinding
heat-sensitivity material.
3. compatible, the grain-size distribution is narrow.The product
granularity is even, degree of fineness may reach 80-320 item.
4. In the engine off situation, may not realizes the product
granularity uniform distribution through the adjustment rotational
speed or the air sorting machine.
5. The main engine top head opens by the air operated spring.The
main body structure may bidirectional opening, be advantageous for
internal part clean and the maintenance.
6. The main attrition uses the upscale alloy tool steel, greatly
lengthened the attrition service life or replaces the cycle.
7. The bearing system uses the import high speed precision bearing,
the movement is steady, the vibration, the noise are low.
8. This pipeline has the rapid take-down structure, is advantageous
for the disassemblage and the clean.
9. Has the cyclone separator and the dust remover, in the
production process does not have the dust.This volume of dust bag
can collect in the air current effectively the fine dust, thus
satisfies the exhaust gas discharge the clean environmental
protection request.
10. The collection may recycle effectively in the bag fine dust.
Grinding effect:porang machine
Detailed images:porang machine
