Food Powder Processing Equipment 5000kg Per Hr Capacity Sri Lanka
Chili Grinding Machine
Product introduct:Sri Lanka Chili Grinding Machine
BSG series self-priming grinders are widely used in food, chemical,
coating, medicine and other industries. In the food field, it can
grind cooked soybeans, sugar, salt, cinnamon, pepper, garlic,
ginger, rice, tea, etc.
Connected with cooling fan, it can grind materials with high oil
content.
Technical data:Sri Lanka Chili Grinding Machine
| Model | BSG-300 | BSG-400 | BSG-500 | BSG-600 | BSG-700 |
| Speed of principal axis(rpm) | 5300 | 4800 | 3800 | 3300 | 2800 |
| Crusher motor(kw) | 5.5 | 7.5 | 15 | 22 | 30 |
| Blower(kw) | 4 | 5.5 | 7.5 | 11 | 15 |
| Discharge motor(kw) | 0.37 | 0.75 | 0.75 | 0.75 | 1.1 |
| Grinding capacity(kg/h) | 50-500 | 100-1000 | 300-1500 | 500-2500 | 1000-5000 |
Working method:Sri Lanka Chili Grinding Machine
The product enters the grinding chamber through the hopper. In a
high-speed rotating surface grinder / under the impact of a hammer,
the appliance is thrown into a fixed ring gear and then cut back.
At the same time, under the impact, cutting and friction of the
disc, the material is fine. Under the negative pressure of the fan
and impeller, the powder is absorbed into the cyclone separator and
discharged through filters and pipes. The pulse dust collector may
also collect some thin dust.
Main Features:Sri Lanka Chili Grinding Machine
(1) The grinding room is equipped with water cooling system to
effectively avoid damage to your product caused by excessive
temperature during grinding.
(2) With the unique impeller design, the air flow generated in the
grinding process will bring the final powder product out of the
grinding chamber together with the hot air. No debris / jam.
(3) The screen is made of high-quality stainless steel. Special
design. When you need a powder and another sieve, you can easily
change the sieve.
(4) Excellent cyclone powder removal system, automatic rotating
powder removal motor and powder removal device, uniform powder
removal, stable powder and dust-free flight.
(5) The machine is also equipped with a dust removal system to
collect the fine powder inevitably generated in the grinding
process into the dust collector, so as to make the automatic
rotation of the final dust removal device more uniform.
(6) All stainless steel structure, in line with GMP standards, food
grade, chemical grade and pharmaceutical grade standards.
(Split type) (Joint type)
Crusher part:Sri Lanka Chili Grinding Machine
Crushing Effect:Sri Lanka Chili Grinding Machine
