3 To 300kg Per Hr Capacity Customized Medicine Grinder Radix
Liquiritiae Milling Machine
This type of BS high-speed hammer crusher is suitable for
pharmaceutical, chemical, food and other industries. It is a good
powder processing equipment. It is not limited by material
hardness, softness and fiber viscosity, and can have good crushing
effect on any material.
Technical data:
| Model | BS-180 | BS-250 | BS-300 | BS-350 |
| Feed size(mm) | <10mm(granule) <15*40*2(leaf) | <10mm(granule) <15*40*2(leaf) | <10mm(granule) <15*40*2(leaf) | <10mm(granule) <15*40*2(leaf) |
| Grind fineness(mesh) | 10-120 | 10-120 | 10-120 | 10-120 |
| Capacity(kg/h) | 3-50 | 10-100 | 20-200 | 30-300 |
| Grind chamber diameter(mm) | 200 | 270 | 330 | 380 |
| Rotor speed(rpm) | 5900/8600 | 4200/6200 | 2600/5100 | 2200/4400 |
| Motor(kw) | 2.2 | 5.5 | 7.5 | 11 |
| Overall size(L*W*H)(mm) | 840*470*1020 | 930*600*1200 | 1000*650*1500 | 1150*700*1600 |
| Weight(kg) | 112 | 210 | 296 | 430 |
Working method:
The machine is composed of frame, crushing chamber and feeding
department. A movable cutter head is installed on the main shaft, a
fixed ring gear is installed in the crushing cavity, and a screen
is installed below the ring gear. When the spindle runs at high
speed, the movable cutter head runs, and the materials are impacted
and rubbed by the fixed ring teeth and the movable hammer. Under
the combined action of shear, shear and impact between the
materials, crushing is realized. The machine has the advantages of
simple structure, firmness and durability, stable operation,
obvious crushing effect and convenient maintenance. The crushed
materials can be discharged directly from the crushing chamber of
the host machine, and the particle size can be obtained by changing
the screens with different pore sizes.
(the speed can also be adjusted to obtain the fineness of the
finished product).
Main features:
1. Wide application range and large processing capacity.
2. Simple and compact structure; Smooth operation.
3. The material grinding process is fast and reliable, and the
grinding degree is adjustable.
4. The surface of the multifunctional grinder is smooth and easy to
clean.
How Can I Buy This Machine?
First of all, discuss all machines details and price with our sales
person.
Secondly, confirm the price and payment terms Trade
assurance/TT/Escrow/Western Union etc.
Thridy, send us purchased order and confirm our Proforma Invoice
and arrange deposit. Once well received the deposit, we will
arrange production.
At last, please arrange balance payment for us once machine is
ready, then we will arrange shipment booking after received the
balance payment and shipping the machine to you.
Please contact us if you have interests in our products.
