Industrial Stainless Steel Customized 60 To 12000L Volume
Horizontal Powder Mixer
FAQ
Q: Where is your factory? How can I visit your factory?
A: Our factory is located In Wuxi province. We are warmly welcome
you visit our Factory if you have a travel plan.
Q: How can I know your machine is designed for my product?
A: If you don't mind, you can send u sample and we test it on the
machine. During that time, we will take video and clearer picture
for you. If chance, we can take video online and show u.
Q: How can I trust you for the first time business?
A: Please note our above business license and certificate. And if
you don't trust us, then we can use Alibaba Trade Assurance
service. It will protect your money during the whole stage of the
transaction.
Q: How about the after service and guarantee period?
A: We make the guarantee time 12 months from the machine's arrival
in buyer's facility and we have a professional team with an
experienced technician to serve abroad and do the best after
service to assure the machine whole life usage.
Q: How do we contact you?
A: Please leave a message and click "send" to send us an inquiry.
Description:
Horizontal ribbon mixer comprises of U-shape barrel,transmisstion
parts and ribbon agitating blades which usually have doubleor
triple layers with outside screw gathering material from side to
center,and inside screw transmitting the material from center to
sides to form convection mix.
Technical data:
| Model | Max work volume(L) | Speed(rpm) | Motor(kw) | Overall size(L*W*H)(mm) | Weight(kg) |
| BSR-100 | 60L | 62 | 3 | 1080*758*615 | 330 |
| BSR-300 | 180L | 49 | 5.5 | 1550*812*1015 | 780 |
| BSR-500 | 300L | 46 | 7.5 | 1975*1059*1120 | 955 |
| BSR-1000 | 600L | 35 | 11 | 2340*1380*1455 | 1400 |
| BSR-2000 | 1200L | 33 | 15 | 2480*1651*1805 | 2500 |
| BSR-3000 | 1800L | 33 | 18.5 | 2945*1896*1980 | 3300 |
| BSR-4000 | 2400L | 29 | 22 | 3038*1946*2205 | 3600 |
| BSR-5000 | 3000L | 29 | 30 | 3932*2010*2035 | 4320 |
| BSR-6000 | 3600L | 26 | 37 | 3938*1882*2246 | 5300 |
| BSR-8000 | 4800L | 26 | 45 | 3986*2160*2516 | 6800 |
| BSR-10000 | 6000L | 19 | 55 | 4500*2270*2667 | 8900 |
| BSR-15000 | 9000L | 17 | 75 | 5363*2470*3020 | 9950 |
| BSR-20000 | 12000L | 17 | 90 | 5670*2650*3497 | 11140 |
Working Method:
BSR series ribbon mixer is mainly composed of mixing barrel, spiral
ribbon and driven parts. The spiral ribbon consists of two layers.
That is, the inner belt makes the material move outward, and the
outer belt makes the material move inward, forming a good material
circulation. The circular motion of the ribbon enables the mixer to
achieve good mixing efficiency in a very short time.
If you are looking for dry powder mixer, such as spice powder
mixer, protein powder mixer, spice powder mixer, our BSR ribbon
mixer is a very good choice.
Main Features:
1. Under the feasibility factor, the mixing effect of the
horizontal belt mixer is not affected by the particle size and
density, and it also has a good mixing effect on the viscous
material.
2. Smooth mixing process to reduce the damage of fragile materials,
flying knife structure in the crusher also played a role.
3. Horizontal structure, low height, easy installation.
4. In the mixing structure, the forward and reverse rotating screw
rods are installed on the same horizontal axis to form a low-power
and high-efficiency mixing environment.
