Got CE Industry Large Capacity Powder And Fluidity Material Mixer
And Blender Machine
About Us:
Brightsail Machinery has found nearly 15 years, who designs and
manufactures overall powder processing solutions for the Chemical,
Pharmaceutical, Food, Mineral, Cosmetic and Plastic industries,
like powder grinding machines, mixing machines, drying
machines...etc.
Brightsail is constantly committed to develop new advanced
techniques and methods on the machines, since our goal is to be
your trusted provider of creative and value added process
solutions.
Pls tell us:
About industrial food ribbon mixer conical ribbon mixer food grade
ribbon mixer
1.What material do you need to mix?industrial food ribbon mixer
conical ribbon mixer food grade ribbon mixer
2.What is the bulk density(g/cm³ or kg/m³) of it?
3.How many liters or kilos of material do you need to mix per
batch?
4.What machine material do you want,all stainless steel 304 type or
only contact part stainless steel 304,other carbon steel type?
Technical Data:
| Model | Max work volume(L) | Speed(rpm) | Motor(kw) | Overall size(L*W*H)(mm) | Weight(kg) |
| BSR-100 | 60L | 62 | 3 | 1080*758*615 | 330 |
| BSR-300 | 180L | 49 | 5.5 | 1550*812*1015 | 780 |
| BSR-500 | 300L | 46 | 7.5 | 1975*1059*1120 | 955 |
| BSR-1000 | 600L | 35 | 11 | 2340*1380*1455 | 1400 |
| BSR-2000 | 1200L | 33 | 15 | 2480*1651*1805 | 2500 |
| BSR-3000 | 1800L | 33 | 18.5 | 2945*1896*1980 | 3300 |
| BSR-4000 | 2400L | 29 | 22 | 3038*1946*2205 | 3600 |
| BSR-5000 | 3000L | 29 | 30 | 3932*2010*2035 | 4320 |
| BSR-6000 | 3600L | 26 | 37 | 3938*1882*2246 | 5300 |
| BSR-8000 | 4800L | 26 | 45 | 3986*2160*2516 | 6800 |
| BSR-10000 | 6000L | 19 | 55 | 4500*2270*2667 | 8900 |
| BSR-15000 | 9000L | 17 | 75 | 5363*2470*3020 | 9950 |
| BSR-20000 | 12000L | 17 | 90 | 5670*2650*3497 | 11140 |
Product Introduction:
BSR seriesribbon blender is an efficient and versatile mixer for
drying particles and powder uniformly. The Ribbon Mixer works best
when mixing dry powder and granules due to the design and shape of
the ribbon and the product container. Can Be used in
pharmaceutical, food, chemical, cosmetics and other industries.
Working Method:
the blending mixer is composed of horizontal mixer and BSR type
mixer. The belt agitator is composed of a group of inner screw
agitators and a group of outer screw agitators. The outer belt
moves the material in one direction and the inner belt moves the
material in the opposite direction. The ribbon can be moved
radially and laterally to ensure complete mixing in a short time.
Main features:
1. Under the feasibility factor, the mixing effect of the
horizontal belt mixer is not affected by the particle size and
density, and it also has a good mixing effect on viscous materials.
2. The smooth mixing process reduces damage to fragile materials,
and the structure of the flying knife also acts as a crusher.
3. Horizontal structure, low height, easy installation.
4. In the stirring structure, the forward and reverse rotating
screws are installed on the same horizontal axis to form a
low-power, high-efficiency stirring environment.
