    Home Besan Vegetable Powder Making Machine , Chickpea Flour Hammer Mill Pulverizer

    Ask Lasest Price
    Brand Name : Brightsail
    Model Number : BS
    Certification : CE ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 30 sets per month
    Delivery Time : 25-30 days
    • Product Details
    • Company Profile

    Home Besan Vegetable Powder Making Machine , Chickpea Flour Hammer Mill Pulverizer

    Home use besan food powder machine chickpea flour hammer mill pulverizer

    This is the smallest grinder machine,also one of the best selling products in our company.It can grind many kinds of materials,such as spices,moringa leaves,date seeds,chickpea,dry flowers...etc.


    Working method:

    This machine consists of three parts: frame, rolling mill cavity and feed part. There is a movable cutter head on the spindle. A fixed ring gear is installed in the grinding chamber. Under the ring gear, there is a strainer. When the spindle works at high speed, the movable cutter head runs together. The material is impacted, rubbed, and cut by the fixed ring gear and movable hammer. The materials also collide with each other. Under the combined effect, they are crushed into powder. The machine has simple structure, stable operation and convenient maintenance. It also has a good effect on abrasive materials.


    Main features:

    1. Simple in structure, few occupied space

    2. Easy to clean, easy to operate

    3. Pulleys are installed at the bottom of the machine, easy to move

    4. Changing powder size by changing difference size of sieve mesh


    Our service:

    1) Professional advice and rich experience help to choose machine.
    2) Any problem before or after delivery, you could find and talk with us anytime.
    3) Related technical information,including operation manual, electric diagram
    4) According to customers' requirement, we can provide installation and employees' training service


    Technical data:

    ModelBS-180BS-250BS-300BS-350
    Feed size(mm)

    <10mm(granule)

    <15*40*2(leaf)

    <10mm(granule)

    <15*40*2(leaf)

    <10mm(granule)

    <15*40*2(leaf)

    <10mm(granule)

    <15*40*2(leaf)

    Grind fineness(mesh)10-12010-12010-12010-120
    Capacity(kg/h)3-5010-10020-20030-300
    Grind chamber diameter(mm)200270330380
    Rotor speed(rpm)5900/86004200/62002600/51002200/4400
    Motor(kw)2.25.57.511
    Overall size(L*W*H)(mm)840*470*1020930*600*12001000*650*15001150*700*1600
    Weight(kg)112210296430
    FAQ:
    1) Q: If I want to come to your company, how do I come?
    Our company is very close to Shanghai. You can go to Shanghai by air, and then go to Shanghai Station. It takes about 40 minutes from Shanghai to Wuxi by high-speed rail, then get off at Wuxi Station, and then we can arrange someone to pick you up to our company. It takes about 40 minutes from the station to our company.
    There is also an airport in Wuxi. If you fly to Wuxi Shuofang Airport, we can also pick you up from Wuxi Shuofang Airport and drive to our company for about 50 minutes from the airport.
    2) Q: How is your machine packaged?
    A: If it is a small machine, it is packed in a wooden box; if it is a large machine or multiple machines, we will divide the machine into several parts, then wrap it with a packaging film, and then fix it in a container with a wire rope to prevent it from shaking during transportation .
