Dried chili spice powder machine 10 to 40 mesh pepper flour hammer
mill grinder
This is the smallest grinder machine,also one of the best selling
products in our company.It can grind many kinds of materials,such
as spices,moringa leaves,date seeds,chickpea,dry flowers...etc.
Working method:
The machine consists of three parts: frame, mill room and feeding
part. There is a movable knife head on the spindle. A fixed gear
ring is installed in the mill room. There is a screen under the
ring of teeth. When the spindle works at high speed, the movable
tool head runs together. The material is impacted, frictioned and
cut by fixed ring and movable hammer. Material also collides with
each other. In the combined effect, they are crushed into powder.
Main features:
1. The crushed materials can be directly discharged from the mill
chamber. If you want to change the powder particle size,just change
the screen inside the mill chamber.
2. The contact part of grinder is made of stainless steel, which
has good corrosion resistance.
3. The inner wall of machine is smooth, no powder and no dead
corners.
4. It is easy to be cleaned, can make the production of medicine,
chemicals, food in line with GMP requirements.
Our service:
1) Pre-sale services:
Based on the clients' request and budget, we will offer project of
equipment pictures, working site videos, plant processing diagram,
assemble drawings, foundation drawings, and plant layout. Clients
are also welcome to visit our factory.
2) After-sale services:
Normally, the equipment warranty is 12 months since installation.
To establish long term cooperation, we will regularly call and
email our clients to check the equipment working condition and
offer suggestions for maintenance.
Technical data:
| Model | BS-180 | BS-250 | BS-300 | BS-350 |
| Feed size(mm) | <10mm(granule) <15*40*2(leaf) | <10mm(granule) <15*40*2(leaf) | <10mm(granule) <15*40*2(leaf) | <10mm(granule) <15*40*2(leaf) |
| Grind fineness(mesh) | 10-120 | 10-120 | 10-120 | 10-120 |
| Capacity(kg/h) | 3-50 | 10-100 | 20-200 | 30-300 |
| Grind chamber diameter(mm) | 200 | 270 | 330 | 380 |
| Rotor speed(rpm) | 5900/8600 | 4200/6200 | 2600/5100 | 2200/4400 |
| Motor(kw) | 2.2 | 5.5 | 7.5 | 11 |
| Overall size(L*W*H)(mm) | 840*470*1020 | 930*600*1200 | 1000*650*1500 | 1150*700*1600 |
| Weight(kg) | 112 | 210 | 296 | 430 |
Good commet from customers:
FAQ:
If you have intention to send a inquiry,could you tell me the
information below
1. Raw material's name, feature(like with oil or sugar), size
before grinding
2. Expected capacity(kg/h)
3. Output size(mesh, mm, um)
4. Industrial Voltage(like 380V, 50HZ, 3 Phase,etc)
Other requirement if you have, please inform us.
