3 to 300 kg per hour turmeric powder making machine spices grinder
with CE
Our BS high speed hammer mill is widely used in the pulverization of materials in the
pharmaceutical, food, chemical and other industries. The fineness
is adjusted between 20-120 mesh. It has the advantages of fine
grain size, low noise, low energy consumption, simple maintenance
and convenient installation.
Working method:
The machine is composed of three parts: frame, mill chamber and
feeding part. There is one moveable cutter head on the principal
axis. And one fixed gear ring is installed in the mill chamber.
Under the gear ring, there is the screen. When the principal axis
works on high speed, the moveable cutter head runs together. The
materials are impacted, rubbed, cutted by the fixed gear ring and
moveable hammer. And materials also collide with each other. Under
the combined effects, they are crushed into powder.
Main features:
1. The crushed materials can be discharged directly from the mill
chamber. The fineness can be adjusted by changing the mesh of
different meshes.
2. The contact part of grinder is made of stainless steel, which
has good corrosion resistance.
3. The inner wall of the machine is smooth without powder or dead
angle.
4. Easy to clean, which can make the production of drugs, chemicals
and food meet GMP requirements.
Our service:
A. Pre-sales service:
1. We provide presales service in various forms, making investment
budge, manufacturing, planning, so that customers can make a
reasonable plan with less cost.
2. We will fist check customer’s goods and goods size, then we will
recommend suitable wrapping machine to 100% suitable.
3. We will recommend and offer machine according to customer’s use
and purchase budget.
B. In-sale service:
1. We will supply each manufacturing step photo for customer
checking on time.
2. We will prepare packing and shipment according to customer’s
needing in advance.
3. Testing the machine and making video for customer’s checking.
C. After-sale service:
1. We will guarantee the machine quality for 1 year.
2. We provide free training and answer customer's question on
technology in time.
Technical data:
| Model | BS-180 | BS-250 | BS-300 | BS-350 |
| Feed size(mm) | <10mm(granule) <15*40*2(leaf) | <10mm(granule) <15*40*2(leaf) | <10mm(granule) <15*40*2(leaf) | <10mm(granule) <15*40*2(leaf) |
| Grind fineness(mesh) | 10-120 | 10-120 | 10-120 | 10-120 |
| Capacity(kg/h) | 3-50 | 10-100 | 20-200 | 30-300 |
| Grind chamber diameter(mm) | 200 | 270 | 330 | 380 |
| Rotor speed(rpm) | 5900/8600 | 4200/6200 | 2600/5100 | 2200/4400 |
| Motor(kw) | 2.2 | 5.5 | 7.5 | 11 |
| Overall size(L*W*H)(mm) | 840*470*1020 | 930*600*1200 | 1000*650*1500 | 1150*700*1600 |
| Weight(kg) | 112 | 210 | 296 | 430 |
