Superfine dry grain powder mill machine corn maize flour powder
making machine
BSP ultra-fine pulverizer is widely used in pulverizing medicine, chemistry, foodstuff,
agricultural and sideline products, such as chinese herb, corn,
rice, spice, wheat, chickpea, dry ginger, garlic, cinnamon,
seaweed, fruit & vegetable dehydration, white sugar, shrimp skin,
chemical materials and so on. It's used in making super fine
powder, with fineness up to 2500 mesh, has the advantages of high
efficiency, easy operating, easy cleaning, steady production, hard
and durable.
Working method:
The material is fed into the crushing chamber by the dosing feeder,
and is impacted, sheared and ground by the high-speed rotating unit
and the stator equipped with grinding teeth. Under the action of
the centrifugal force of the classification wheel and fan in the
impact mill, the powdery material enters the classification zone
and is qualified. The powder was collected by the cyclone dust
collector and the bag dust collector, and the oversized powder
continued to be ground.
Main features:
1. Compact design and reasonable structure. The material is
equipped with an internal grading mechanism that allows grinding
and grading to occur simultaneously, thereby reducing energy
consumption.
2. Equipped with a fan, continuous heat dissipation, suitable for
grinding of heat-sensitive materials.
3. The bearing system adopts high-speed precision bearings imported
from abroad, and the whole machine runs smoothly with low vibration
and noise.
4. The pipeline is quickly dismantled for quick and easy
disassembly and cleaning.
5. Equipped with cyclone separator and dust collector, no flying
powder phenomenon during production. The dust bag can effectively
collect the fine powder in the air stream, and meet the
requirements of clean and environmental protection for exhaust
emissions.
6. The fine powder collected in the dust bag can be effectively
recycled, thereby reducing material loss.
Our company:
We, Brightsail Machinery Co.,Ltd is specialized in making these
machines which can be applied in food,chemical,medicine,pharmacy
and other industries.Our company has been one of the most famous
powder equipment manufactures in the industry.
Since we have sold many machines to more than 50 countries,we have
enough experience and technology to help you to find a most
suitable machine.
If you are interested in our machine and want to know more
details,please don’t hesitate to contact me.
Technical data:
| Model | BSP-350 | BSP-450 | BSP-500 | BSP-750 |
| Input size(mm) | <15 | <15 | <15 | <15 |
| Fineness(mesh) | 60-2500 | 60-2500 | 60-2500 | 60-2500 |
| Capacity(kg/h) | 20-200 | 40-500 | 60-800 | 120-1800 |
| Crush motor(kw) | 11 | 18.5 | 30 | 55 |
| Grade motot(kw) | 1.5 | 4 | 5.5 | 11 |
| Blower(kw) | 7.5 | 11 | 18.5 | 37 |
| Feed motor(kw) | 0.55 | 0.55 | 0.75 | 1.5 |
| Discharge motor(kw) | 0.75 | 0.75 | 1.1 | 1.5 |
| Speed of principle axia(rpm) | -6500 | -5350 | -4600 | -3100 |
| Grading impeller speed(rpm) | 4000 | 4000 | 3500 | 3000 |
| Weight(kg) | 1600 | 1800 | 2300 | 3100 |
