60-2500 mesh Customized High Quality Herb Grinder Used In Many
Fields
BSP custom grinder herb is composed of crusher, cyclone separator,
dust collector, blower, electric control box, etc. it has the
functions of winnowing, no screen, no net, uniform particle size
and continuous processing. In line with the international advanced
level, it is suitable for grinding materials in pharmaceutical,
chemical and food industries.
Main components:
1. Pulse dust collector: Collect dust in the dust collector. There
are multiple dust-proof bags in the box, and the dust-proof bag
bracket is also made of stainless steel, which is easy to
disassemble. Pulse spray cleaning, dust collection is extremely
convenient.
2.Crusher part: The motor on the left is a crushing motor, and the
motor on the right is an electromechanical machine. Using small
screw feeder to ensure uniform and controllable feeding speed.
3.The material enters the grinding cavity through the screw
conveyor, and is cut and ground by the rapidly rotating blade in
the grinding cavity. The powder enters the classification chamber
through the guide ring.
4.Cyclone separation: Cyclone separation can separate dust and
powder (particles). The rotary valve is made of stainless steel
with uniform powder speed. Easy to clean and disassemble.
Main features:
(1) It has the advantages of simple structure, easy installation
and maintenance;
(2) there is a water cooling sleeve around the grinding room, and
the bearing can cool the machine;
(3) the motor, electrical appliances, bearings and operating parts
are all world advanced brands;
(4) there is no dust in the production process, and the dust can be
collected in the dust box;
(5) the particle size can be changed without changing the screening
speed.
Drawing:
Technical data:
| Model | BSP-350 | BSP-450 | BSP-500 | BSP-750 |
| Input size(mm) | <15 | <15 | <15 | <15 |
| Fineness(mesh) | 60-2500 | 60-2500 | 60-2500 | 60-2500 |
| Capacity(kg/h) | 20-200 | 40-500 | 60-800 | 120-1800 |
| Crush motor(kw) | 11 | 18.5 | 30 | 55 |
| Grade motot(kw) | 1.5 | 4 | 5.5 | 11 |
| Blower(kw) | 7.5 | 11 | 18.5 | 37 |
| Feed motor(kw) | 0.55 | 0.55 | 0.75 | 1.5 |
| Discharge motor(kw) | 0.75 | 0.75 | 1.1 | 1.5 |
| Speed of principle axia(rpm) | -6500 | -5350 | -4600 | -3100 |
| Grading impeller speed(rpm) | 4000 | 4000 | 3500 | 3000 |
| Weight(kg) | 1600 | 1800 | 2300 | 3100 |
