50-500kg Per Hour Capacity Customized Stainless Steel Sesame
Grinding Machine
Product Introduction Of Sesame Grinding Machine:
BS sesame seeds grinding machine is specially used for grinding
sesame, peanut, almond and other high oil content materials. Our
almond mill can grind these materials at room temperature. Widely
used in pharmaceutical, chemical, food and other industries. BS
peanut grinder is designed and developed by our company, filling
the gap of domestic oil mill, reaching the international advanced
level.
Working Principle Of Sesame Grinding Machine:
The raw materials are fed into the drum area by the hopper and
crushed into powder by the drum. By adjusting the distance between
the two rollers, different sizes of finished products can be
obtained.
Technical Data Of Sesame Grinding Machine:
| Model | BS150-3 | BS150-4 | BS250-3 | BS250-4 | BS500-3 | BS500-4 |
| L(mm) | 780 | 780 | 920 | 920 | 1340 | 1340 |
| W(mm) | 670 | 670 | 720 | 720 | 1210 | 1210 |
| H(mm) | 1600 | 1850 | 1750 | 2000 | 2000 | 2250 |
| Weight (kg) | 350 | 520 | 580 | 750 | 1200 | 1400 |
| Capacity(kg/h) | 50-200 | 50-200 | 100-400 | 100-400 | 200-500 | 200-500 |
| Motor(kw) | 2.2 | 3 | 5.5 | 7.5 | 11 | 15 |
| Roller diameter(mm) | ϕ150 | ϕ150 | ϕ150 | ϕ150 | ϕ219 | ϕ219 |
| Roll length(mm) | 150 | 150 | 250 | 250 | 500 | 500 |
| Roller speed(r/min) | / | Driving wheel:33 | / | Driving wheel:33 | / | Driving wheel:33 |
| / | Passive wheel:18 | / | Passive wheel:18 | / | Passive wheel:18 |
| Driving wheel:33 | Driving wheel:42 | Driving wheel:33 | Driving wheel:42 | Driving wheel:33 | Driving wheel:42 |
| Passive wheel:18 | Passive wheel:22 | Passive wheel:18 | Passive wheel:22 | Passive wheel:18 | Passive wheel:22 |
| Driving wheel:42 | Driving wheel:48 | Driving wheel:42 | Driving wheel:48 | Driving wheel:42 | Driving wheel:48 |
| Passive wheel:22 | Passive wheel:26 | Passive wheel:22 | Passive wheel:26 | Passive wheel:22 | Passive wheel:26 |
| Driving wheel:48 |
| Passive wheel:26 |
Detailed Images Of Sesame Grinding Machine:
Applicable Materials Of Sesame Grinding Machine:
We Can Also Provide Related Machines To Deal With Nuts Such As
Peanuts, Sesame Seeds And Almonds. Such As roasting machine, drying
Oven, Paste Making Machine ...
If You Are Interested In Our Products, Please Contact Us.
Our Services:
1. Pre-sales service:
Inquiry and consulting support with 24 hours;
Machine sample test service;
Factory visit
2. After-sales service:
Instructing how to install and use the machine;
one year warranty;
video support;
engineer is available to go to user's factory to help install and
train
